Warehouse Logistics Commercial Steel Shelves VNA Pallet Shelving

1. Produkbeskrywing:

Narrow Aisle Rack System (VNA) is one kind of specifical pallet rack.

1.Narrow aisle rack provides high density storage while still allowing individual access to all pallets.

2. Narrow aisle rack must be served by special three-way forklift machine.

3.Very narrow aisle,operating aisle is just about 1.7m.

4.Floor rail must be installed to be with the three-way forklift operation.

Narrow Aisle pallet Rack photos:

VNA_1 (19)

VNA_1 (14)

2. Narrow aisle rack Gedetailleerde inligting:

specification of racks	lengte	1200/1900/2300/2700/3300/3600(mm)
	diepte	800-1200 (mm)
	hoogte	2000-13000 (mm)
regop	90 * 70,100 * 80,120 * 95
Beam	8050 & 10050 & 12050 &14050
dikte	1.8mm, 2.0mm, 2.3mm, 2.5mm
capacity/layer	1-4 tons each level
notas	1. All racking shall be fixed onto the ground by means of Expansion bolts
	2. Each beam is secured by 2 safety pins
	3. There are link bars between two back-to-back rack rows.
	4. Protector is recommended to mount in the junction of over two directions

VNA Racking 3

3.Special requirements for narrow aisle racking system:

1) Special VNA forklift truck and guidance systems

2) Very flat engineered floor surface

3) Semi automatic pallet positioning controls for accurate high level placement and retrieval

4) Obviously it must have excellent rigidity and close engineering toleransies

5) Beams at all storage levels unless low profile rails or wire guidance system adopted

4.Packing & shipping:

1.Experienced export packing uprights and beams' both end with cardboard ,then outside bundled tightenly with plastic belts.

2.According to the customers's special requirement.

3.Very quick delivery,we promise within 15 days after receiving deposit.

5.Our service:

1. After long time's usage, you can check if the bolts are still tight enough to make the racks more safety;

2. If there is some striking on the upright protector to make it distortion, you can rectify it or contact us for some new;

3. Our racks are assembled, you can adjust them freely based on your actual requests, if need professional guidance, contact freely with our service team for sommige besonderhede.

6.Quotation for floor rail racking:

You can send us your CAD drawing,or pls let us know the following info and we will design drawings for U:
1).Size of your warehouse (Length x Width x Clear height,door location).If possile,pls send us your warehouse drawing.
2).Pallet Size(W*D*H) & the entry direction.
3).How many levels you would like.

4).Laai gewig each level.

5).The aisle width for forklift.

7.Company information:

maatskappynaam	Shanghai Everunion Logistics Equipment Co.,Ltd
Ligging	Factory is in Nantong city, convenient transport
Hoof produkte	Standard pallet racking, Narrow aisle rack and other rack system..
Hoofmarkte	Australasia,Europe,Asia,Central America,South America,North Africa ...(more than 80 Countries)
Annual sales amount	25 millions US dollar
Gehalte	ISO9001: 2008
Veiligheid standaard	AS4084 and FEM 10.202
Company Concept	Personality is Product,Standard is Quality

Everunion produkte

vna pallet shelving for logistics and storage use-57

maatskappy-inligting

NANTONG FABRIEKSFOTO

pakhuis swaargewig paletrak

Nantong Everunion Logistics Equipment Co., Ltd. is specializes in designing, manufacturing, intallaltion and debugging of racks .As a professional racking manufacturer , we can provide a wide range of racks, such as conventional pallet racks, Double deep racks, Drive-in racks, Narrow aisle racks, Push back racks, Radio shuttle racks, Gravity pallet racks, Cantilever racks ,Mezzanine, steel platform and long span shelving system etc..

Our factory is located in Kunshan, Jiangsu province, it covers an area of more than 10,000 square meters, also we have established a team of professional specialists to solve logistics problem, and they are preparing to offer the technical consultation and storage design at any time. Everunion has CE and ISO certificate. Our high standards and strict requirements make our high quality products . For high quality , competitive price and good service ,our products have won a high phrase among domestic and foreign markets .

xiaoyu 3m

We mainly export our racks to Mid-East, South America, Center America, Oceania, Africa, Europe and some Asian countries, such as Canada, Australia, Germany, Italy, Belgium, Greece, Czech Republic, Philippines, Indonesia, Jordan, Sri Lanka, Korea, Japan, Mexico, Guatemala, Chile, Brazil, Norway, Singapore and so on.

Ons sal altyd al die probleme wat verband hou met logistiek vir kliënte oplos met ons beste produkte en beste dienste. As jy belangstel in ons produkte, voel asseblief vry om ons te kontak vir meer inligting.

pakhuis swaargewig paletrak

CE en ISO SERTIFIKAAT

pakhuis swaargewig paletrak

TOETSVERSLAG

pakhuis swaargewig paletrak

FAQ

V1: Is u 'n vervaardiger of handelsonderneming?

A: Ons is 'n professionele rakvervaardiger Nantong, Jiangsu , we have sales office in shanghai .From shanghai to our factory , it will take about 2 hours by car .

V2: wat is u waarborgtyd?

A: Die hoë standaarde in die ontwerp en vervaardiging verseker dat ons die produkte ondersteun met 'n 10 jaar waarborgtyd vir jou normale gebruik, dit is die langste vervaardiger se waarborg!

V3: Wat is afleweringstye?

A: Ons het 2 GEMA poeierbedekkingslyne en 4 outomatiese sweismasjiene, wat ons kan verseker baie kort afleweringstyd- minder as 18 dae.

V4: Wat is u betalingstermyn?

A: 1) As algemeen, 30% T/T-afbetaling en 70% teen BL-kopie.

2) 100% LC op sig

V5: Is monsters beskikbaar?

A: Ja, ons kan 'n paar gedeeltes van monsters per uitdruklik vir u verwysing stuur.

V6: wat is die laaipoort?

A: Shanghai hawe is die naaste hawe aan ons.

V7: wat is die materiaal en afwerking van jou rakke?

A: Oor die algemeen is ons materiaal staal Q 235, afwerking: Poedercoating .

V8: Hoe kan ek u vinnige kwotasie op my paletrekprojek kry?

A: Aangesien verskillende kliënte en projekte verskillende behoeftes van rakafmetings en spesifikasies het, soos algemeen, vir vinnige kwotasie, moet ons die volgende inligting ken

1) Vereiste Palletrek-afmeting: Hoogte * Diepte * Lengte?

2) Aantal vlakke?

3) Laaivermoë van elke vlak?

4) Rekkie Hoeveelheid?

V9: Hoeveel rakke kan in 'n 20'-houer of 'n 40'-houer gepas word

A: Ons kan jou vertel as jy ons die onderstaande inligting verskaf:

1) rek afmeting

2) rakhoeveelhede

3) rek laai gewig

Ons Advantage

1) Ons vinnige antwoord

Vir 'n vinnige kwotasie, stuur net e-pos aan ons. Ons belowe om binne 12 uur met 'n prys te antwoord

2) Ons kort afleweringstyd

Vir selektiewe palletrekbestellings sal ons belowe om binne 15 dae te produseer. As 'n fabriek kan ons die afleweringstyd volgens die formele kontrak bepaal.

3) Ons spesiale uitvoerpakkette.

Ons het plastiekknipsels op die balke om die balke te beskerm teen oppervlakskade tydens die vervoer. Ons het die hele staanders met deursigtige plastiekfilm toegedraai.

4) Meer as 20 jaar ondervinding in rakvervaardiging en uitvoer
